• Soldered onboard Intel® Core™ Ultra 2 Processor Series
• Intel® AI Boost - Integrated NPU accelerator
• Dual Channels DDR5 5600MT/s up to 96GB SO-DIMM
• Multiple I/O 2.5GbE Ethernet, PCIe Gen4, USB3.2, SATA3.0
• Support Max. 4 independent displays
• 8.5V~20V Wide Range Voltage Input
• Wide Range Operating Temp.: 0 ~ 60°C
| CPU | Soldered onboard Intel® Core™ Ultra Processor - Core Ultra 7 255H 2.0GHz / 5.1GHz (Turbo) - Core Ultra 5 225H 1.7GHz / 4.9GHz (Turbo) - Core Ultra 7 255U 2.0GHz / 5.0GHz (Turbo) - Core Ultra 5 225U 1.5GHz / 4.8GHz (Turbo) |
| Memory | 2 x DDR5 SO-DIMM sockets |
| BIOS | AMI UEFI BIOS |
| Watchdog Timer | 1~255 levels reset |
| USB Port | 11 x USB ports: - 8 x USB 2.0 ports - 3 x USB 3.0 ports |
| Serial Port | 2 x UART ports (RX/TX only) |
| Expansion Bus | 1 x PCIex8 lanes (H series only) 2 x PCIex4 lanes 8 x PCIex1 lanes (or 1 x PCIex4 + 4 xPCIex1) I²C, GPIO, SMBUS, LPC Interface |
| Storage | 2 x SATA ports with 600MB/s HDD transfer rate 1 x NVMe SSD (Share With PEG 1 x PCIex4 lanes) |
| Ethernet Chipset | 1 x Intel® i226 series PCIe 2.5GbE Ethernet controller |
| Audio | HD audio link |
| TPM | Supports TPM 2.0 |
| Graphic Chipset | Integrated Intel® Arc™ or Iris Xe Graphics (depends on CPU SKU) |
| Graphic Interface | 1 x Dual Channel 24-bit LVDS (default) or eDP 1 x Analog RGB port 3 x DDI ports |
| OS support | Windows 10 64-bit Windows 11 64-bit Linux: Ubuntu |
| Power Requirement | 8.5V~20V wide range voltage input, +5VSB |
| Power Consumption | TBD |
| Operating Temp. | 0 ~ 60°C (32 ~ 140oF) |
| Operating Humidity | 10 ~ 95% @ 85oC (non-condensing) |
| Dimensions (L x W) | 95 x 95 mm (3.7” x 3.7”) |
| 型号 Model | 描述 Description |
| HS-96U0-C1 | Heat sink with Fan (95 x 95 x 37.6 mm) HS-96U0-F1-T |
| HS-96U0-F1-T | Heat spreader, threaded standoffs (bore hole) (95 x 95 x 11 mm) |
| HS-96U0-F1-NT | Heat spreader, non-threaded standoffs (bore hole) (95 x 95 x 11 mm) |
| PBE-1705 | COM Express® type 6 carrier board (ATX form factor) |
| CBK-03-1705-00 | Cable kit 1 x SATA cable 2 x COM Flat cables |
| 标配 Standard | 型号 Model | 描述 Description |
| EmCOMe-i96U0-255H | Intel® Core™ Ultra 7 255H COMe Compact Type 6 CPU module, 0 ~ 60°C | |
| EmCOMe-i96U0-225H | Intel® Core™ Ultra 5 225H COMe Compact Type 6 CPU module, 0 ~ 60°C | |
| EmCOMe-i96U0-255U | Intel® Core™ Ultra 7 255U COMe Compact Type 6 CPU module, 0 ~ 60°C | |
| EmCOMe-i96U0-225U | Intel® Core™ Ultra 5 225U COMe Compact Type 6 CPU module, 0 ~ 60°C |
