Intel Core i5-1235U(1.3 GHz/4.4GHz),10(Threads: 12)
Intel Core i7-1255U(1.7 GHz/4.7GHz),10(Threads: 12)
Intel Core i3-1315U(1.2 GHz/4.5GHz),6(Threads: 8)
Intel Core i5-1335U(1.3 GHz/4.6GHz),10(Threads: 12)
Intel Core i7-1355U(1.7 GHz/5.0GHz),10(Threads: 12)
支持1 x SO-DIMM DDR5，最大支持32GB
支持4个千兆网络
支持2 x HDMI 扩展同步/异步显示/双显
支持M.2 SSD，M.2 WIFI, M.2 2280(NVMe),MiniPCIe，3042/3052 5G
10V~36V宽压输入
| 处理器 Processor | Intel Core i5-1235U(1.3 GHz/4.4GHz),10(Threads: 12) Intel Core i7-1255U(1.7 GHz/4.7GHz),10(Threads: 12) Intel Core i3-1315U(1.2 GHz/4.5GHz),6(Threads: 8) Intel Core i5-1335U(1.3 GHz/4.6GHz),10(Threads: 12) Intel Core i7-1355U(1.7 GHz/5.0GHz),10(Threads: 12) |
| 内存 Memory | 1 x SDRAM DDR5 (max. 48G) |
| 图形 Graphics | Intel UHD Graphics |
| 存储 Storage | 1 x M.2 2242 SSD(SATA Signals)[1][2] 1 x M.2 2280 NVMe(PCIe x 4 signals) 1 x 2.5"SATA 3.0 HDD/SSD[2] |
| 操作系统 OS | Windows 10，Windows 11， Ubuntu22.04 |
| 看门狗定时器 Watchdog Timer | Programmable 255 levels timer interval, from 1~255 sec/min |
| 网口 Ethernet | LAN1：1 x RJ45 I219-LM for 10/100/1000 Mbps, support Wake On LAN LAN2/3/4：3 x RJ45 Intel I226-V for 10/100/1000 Mbps,support Wake On LAN |
| 显示 Video | 2 x HDMI Up to 4096 x 2304 @ 60 Hz |
| 音频 Audio | 1 x Audio(Line-out & Mic-in ) ( 芯片888S/897) |
| 串口 COM | 4xRS-232/422/485(default RS-232) with auto flow control【5PIN Phoenix Terminal Head Interface] |
| USB | 3 x USB3.2 3 x USB2.0 |
| 按钮 Button | 1 x Power button W/Led |
| 远程开关 Remote ON-OFF | 1 x SW |
| 扩展接口 Expansion | 1 x full-size MiniPCIe (PCIe/ USB2.0 signal supported ) 1 x E-Key M.2 2230 slot (PCIe x 1 / USB2.0 signal supported) 1 x M.2 (M key) for 2280 NVMe (PCIe x 4 signals) 1 x M.2 3042/3052 cellular modules (USB3.2 Signals)[1] |
| GPIO | 1 x 8bit programmable GPIO pin header 【3.3 | 5V Jump adjustable】 |
| SIM 卡 | 1 x SIM Card socket for 4G&5G module |
| TPM2.0 | DTPM2.0 function |
| USB | 2 x USB2.0 by pin head |
| 串口 | 2 x COM RS232 by 3-wire Pin head |
| 操作温度 OperatingTemp. | -20℃ ~ 60℃ (SSD), 0℃ ~ 40℃ (HDD) |
| 存储温度 Storage Temp. | -40℃ ~ 85℃ |
| 湿度Relative Humidity | 5% ~ 95%, 非凝结状态Non-condensing |
| 振动 Vibration | SSD: 5~500Hz, 2Grms operation HDD: 5~500Hz, 1Grms operation |
| 机械冲击 Shock | Operation: 10G@11ms Non-operation: 30G@11ms |
| 电源输入 Power Input | 10~36V 宽压输入, 2-pin phoenix connector |
| 外观 Housing | 铝合金 Aluminum Alloy |
| 安装方式 Mounting | Desk-Mount, Wall-Mount, DIN-Rail(optional) |
| 尺寸 Dimension | 200*140*55.7mm (基础层） 200*140*79.5mm（两层） |
| 重量 Weight | 1.8KG |
| 安规认证 Safety Certification | CCC, CE, FCC |
| 型号 Model | CPU | HDMI | USB3.2 | USB2.0 | GbE | COM | 电源 |
| CEAS-1123-W44A | Intel Core i5-1235U | 2 | 3 | 3 最多 5 ( 可选 ) | 4 | 4, 最多 6 ( 可选 ) | 10-36V |
| CEAS-1125-W44A | Intel Core i7-1255U | 2 | 3 | 3 最多 5 ( 可选 ) | 4 | 4, 最多 6 ( 可选 ) | 10-36V |
| CEAS-1131-W44A | Intel Core i3-1315U | 2 | 3 | 3 最多 5 ( 可选 ) | 4 | 4, 最多 6 ( 可选 ) | 10-36V |
| CEAS-1133-W44A | Intel Core i5-1335U | 2 | 3 | 3 最多 5 ( 可选 ) | 4 | 4, 最多 6 ( 可选 ) | 10-36V |
| CEAS-1135-W44A | Intel Core i7-1355U | 2 | 3 | 3 最多 5 ( 可选 ) | 4 | 4, 最多 6 ( 可选 ) | 10-36V |
| 标配 Standard | 型号 Model | 描述 Description |
| 35091DM00-JTU-G | 1 x SATA cable with screw hole 90¢ X/180¢ X 150mm | |
| 2G151DE00-HUH-G | 2 x M2-2242_THERMAL-PAD.27*24*2 | |
| 2G151DS00-HUH-G | 1 x Memory_thermal-pad_3w-1_5,HS300 3W/ mk,57*12.5*1.5 | |
| 34046QH00-GLA-G | 1 x 2pin DC-IN 公头Connector,5mm | |
| 34046QJ00-600-G | 1 x 2pin DC-IN SW Connector,3.5mm | |
| 34046KC00-600-G | 2 x Terminal Blocks,DIP-10 Connector,3.5mm | |
| 2A584QQ00-G7D-G | 1 x P 頭螺絲M3*3_ 耐落,pan head screw M3*3_tslgnylok, carbon steel | |
| 2A582LF00-G7D-G | 2 x SCREW P HEAD M3*P0.5*6L,LFNI | |
| 2A582LB00-G7D-G | 1 x SCREW I HEAD M2*P0.4*3L,LFNI NYLOCK | |
| 2A586GM00-G7D-G | 4 x 螺絲,SCREW,SWRCH18A,M3,4,Machine | |
| 2T71A7V00-3G1-G | 2 x Monunting,NA,96*29.5*6 | |
| 2A5863G00-G7D-G | 4 x SCREW M3X6 HEX/W,SWRCH18A,M3,6,Machine | |
| 2T71E5000-JTW-G | 1 x 脚架,CEAS-113X-MOUNT,NA,242*45*1.5 | |
| 2T71BM700-JV3-G | 4 x 螺钉,screw, 黑色，锌镍合金,M3*6F |
| 选配 Optional | 型号 Model | 描述 Description |
| CTO-090W-HK00 | HK 12V 90W adapter,150cm power cord | |
| CTO-090W-LT03 | Lite-on 90W适配器，20V+1.5米 powercord | |
| 35105R800-JTU-G | 8bit GPIO Cable (DB9 Connect ) | |
| 35109W100-JTU-G | Com5/6 RS232 cable,250mm Y Cable | |
| 2T71D6T00-JWQ-G | 導軌卡扣,Din rail 35mm W25,N/A,25X47.8,G,00 |
