Intel® Tiger lake i3-1115G4 3.0G(6M Cache,up to 4.1GHz)
Intel® Tiger lake i5-1135G7 2.4G(8M Cache,up to 4.2GHz)
Intel® Tiger lake i5-1145GRE 1.5G(8M Cache,up to 4.1GHz)
Intel® Tiger lake i7-1165G7 2.8G(8M Cache,up to 4.7GHz)
支持1 x SO-DIMM DDR4-3200，最大支持32GB
支持4个千兆网络
支持DP/HDMI 扩展同步于/异步显示/3显
支持M.2 SSD，M.2 WiFi, Mini-PCIe
10~36VDC
| 处理器 Processor | Intel® Tiger lake i3-1115G4 3.0G(6M Cache,up to 4.1GHz) Intel® Tiger lake i5-1135G7 2.4G(8M Cache,up to 4.2GHz) Intel® Tiger lake i5-1145GRE 1.5G(8M Cache,up to 4.1GHz) Intel® Tiger lakeI7-1165G7 2.8G(8M Cache,up to 4.7GHz) |
| 内存 Memory | 1 x SDRAM DDR4 3200 MHz (max. 32G) |
| 图形 Graphics | Intel® Iris® Xe graphics, up to 96 graphics execution units (EU) |
| 存储 Storage | 1 x M.2 2242 1 x Sata 3.1(2.5 寸硬盘) |
| 操作系统 OS | Windows 10, Ubuntu20.04 |
| 看门狗定时器 Watchdog Timer | Programmable 255 levels timer interval, from 1~255 sec/min |
| 网口 Ethernet | 1 x RJ45 Intel i219LM GbE (10/100/1000 Mbps) 3 x RJ45, Intel® i210 GbE (10/100/1000 Mbps)【Colay 1211GbE】 |
| 显示 Video | 2 x HDMI, up to 4K x 2K x 24bpp@24Hz 1 x DP, up to 4096 x 2304 x 36bpp@60Hz |
| 音频 Audio | 1 x Audio(Line-out & Mic-in ) ( 芯片888S/897) |
| 串口 COM | 4 x RS-232/422/485 (default RS-232) with auto flow control |
| USB | 3 x USB3.2 Gen. 2 3 x USB2.0 |
| 按钮 Button | 1 x Power button W/Led |
| 远程开关 Remote ON-OFF | 1 x SW LED |
| 扩展接口 Expansion | 1 x E-Key M.2 2230 slot (PCIe X1 / USB2.0 signal supported) 1 x mPCIe (PCIe/ USB2.0/USB 3.0 signal supported) |
| GPIO | 1 x 8bit programmable GPIO pin header【3.3 | 5V Jump adjustable】 |
| SIM 卡 | 1 x SIM Card socket for 3G/4G module |
| USB | 2 x USB 2.0 by Pinhead |
| 串口 | 2 x COM232 by Pinhead |
| 操作温度 OperatingTemp. | -20℃ ~ 60℃ (SSD), 0℃ ~ 40℃ (HDD) |
| 存储温度 Storage Temp. | -40℃ ~ 85℃ |
| 湿度Relative Humidity | 5% ~ 95%, 非凝结状态Non-condensing |
| 振动 Vibration | SSD: 5~500Hz, 2Grms operation HDD: 5~500Hz, 1Grms operation |
| 机械冲击 Shock | Operation: 10G@11ms Non-operation: 30G@11ms |
| 电源输入 Power Input | 10~36VDC, 2-pin phoenix connector |
| 外观 Housing | 铝合金 Aluminum Alloy |
| 安装方式 Mounting | Desk-Mount, Wall-Mount, DIN-Rail(optional) VESA-mount (75 x 75mm, 100 x 100mm optional) |
| 尺寸 Dimension | 224 x 140 x 49.2 mm |
| 重量 Weight | 1.6 kg |
| 安规认证 Safety Certification | CCC, CE, FCC |
| 型号 Model | CPU | DP | HDIM | USB3.0 | USB2.0 | GbE | COM | SW | M.2 | SATA | Mini-PCIe | M.2 2230 | 电源 |
| CES-R111-W44A | Intel® Tiger lake i3-1115G4 | 1 | 2 | 3 | 3 最多 5 ( 可选) | 4 | 4, 最多 6 ( 可选) | 1 | 1 | 1 | 1 | 1 | 10-36V |
| CES-R113-W44A | Intel® Tiger lake i5-1135G7 | 1 | 2 | 3 | 3 最多 5 ( 可选) | 4 | 4, 最多 6 ( 可选) | 1 | 1 | 1 | 1 | 1 | 10-36V |
| CES-R114-W44A | Intel® Tiger lake i5-1145GRE | 1 | 2 | 3 | 3 最多 5 ( 可选) | 4 | 4, 最多 6 ( 可选) | 1 | 1 | 1 | 1 | 1 | 10-36V |
| CES-R116-W44A | Intel® Tiger lake i7-1165G7 | 1 | 2 | 3 | 3 最多 5 ( 可选) | 4 | 4, 最多 6 ( 可选) | 1 | 1 | 1 | 1 | 1 | 10-36V |
| 标配 Standard | 型号 Model | 描述 Description |
| 2G151DE00-HUH-G | M2-2242_THERMAL-PAD_28*26*2 | |
| 2G151DT00-HUH-G | Memory_thermal-pad_57*12.5*1.5, | |
| 34046QJ00-600-G | 1 x 2P Remote conn (3.50), female | |
| 34046QH00-GLA-G | 2pin DC-IN Phoenix Connector,5mm,FOXCONN |
| 选配 Optional | 型号 Model | 描述 Description |
| CTO-090W-HK00 | HK 12V 90W adapter,150cm power cord | |
| CTO-135W-LT00 | LITEON 19V 135W adapter,150cm power cord | |
| 35105R800-JTU-G | 8bit GPIO Cable (DB9 Connect ) | |
| 35107YP00-JTU-G | 2*RS232 Y Cable | |
| 061001D00-187-G | Wireless Card,M.2,Bluetooth,INTEL,3165.N | |
| 2T71A7Y00-JTW-G | DIN-RAIL/VESA Bracket,165mm*115mm*10.5mm |
