Intel®10代酷睿 i9/i7/i5/i3/至强®处理器, 功耗最高支援到95W, 支持intel vPro
双通道4插槽 DDR4 ECC/Non-ECC 2400/2666/2933MHz, 高达128GB (酷睿 i5/i7/i9 只支持Non-ECC)
支持VGA, DVI-D, DP++三屏显示
支持三Intel GbEs, USB3.2 Gen1/2, 16位GPIO
内置PCI,PCIe插槽，支持多种模块扩展
抗震动磁盘架设计，可支持2个3.5"HDD,1个2.5"SSD硬盘
前部可访问 USB接口，更易于数据传输
海岸线上的USB端口支持Ennoconn USB SR Pro
| 处理器 Processor | Intel® 10th Gen Core ™ i9/i7/i5/i3/Xeon®Processor, LGA1200, TDP up to 95W |
| 芯片组 Chipset | Intel® W480E |
| 内存 Memory | 4 x DDR4 ECC/Non-ECC 2400/2666/2933 MHz U-DIMM Slot, up to 128GB (Core ™ i5/i7/i9 only support Non-ECC) |
| 图形 Graphics | Intel® UHD Graphics 630 |
| 存储 Storage | 4 x SATA 3.0, 1 x M.2 (SATA3.0/PCIe 3.0 X4) 2242/2280 |
| 操作系统 OS | Windows 10, Linux |
| 看门狗 Watchdog Timer | System Reset, Programmable via software from 1 to 255 seconds |
| 信赖平台模块 TPM | Nuvoton TPM2.0(optional, need MOQ) |
| 网口 Ethernet | 1 x Intel® i219-LM GbE, 2 x Intel® i211-AT/i210-AT (10/100/1000 Mbps) |
| 显示 Video | 1 x DVI-D: max resolution up to 1920 x 1200 @ 60Hz 1 x VGA: max resolution up to 1920 x 1200 @ 60Hz 1 x DP++: max resolution up to 4096 x 2304 @ 60Hz |
| 音频 Audio | 1 x Line-out, Line-in, Mic-in |
| 串口 COM | 1 x RS232/422/485 (with auto flow control) |
| USB | 6 x USB3.2 Gen2, 2 x USB2.0 |
| 按钮 Button | 1 x Power Button, 1 x Reset Button |
| 指示灯 LED | 1 x Power LED, 1 x HDD LED |
| 扩展接口 Expansion | 2 x PCIe3.0 X16 (1 x 16 or 2 x 8 link), 3 x PCIe X4 (X4 link), 2 x PCI |
| 风扇 FAN | 1 x CPU Fan, 2 x System Fan |
| USB | 6 x USB2.0 (1 x Type-A) |
| GPIO | 1 x 16 bit GPIO |
| 串口 COM | 1 x RS232/422/485 (with auto flow control), 2 x RS232/485, 2 x RS232 |
| LPT | 1 x LPT |
| PS/2 | 1 x PS/2 (keyboard and mouse) |
| 操作温度 Operating Temp. | 0℃ ~ 40℃ |
| 存储温度Storage Temp. | -20℃ ~ 60℃ |
| 湿度Relative Humidity | 5% ~ 95%, 非凝结状态Non-condensing |
| 随机振动 Random Vibration | 5~500Hz, 1Grms (HDD)operation |
| 正弦振动 Sine Vibration | 5~500Hz, 2G Non-operation |
| 机械冲击 Shock | 10G @ 11ms operation |
| 电源输入 Power Input | 100~240V(AC) |
| 电源功耗 Power Watt | 250W |
| 外观 Housing | SGCC |
| 尺寸 Dimension | 481.6(L) x 450.0(W) x 88.6(H)mm |
| 重量 Weight | 10kg( 约) |
| 安装方式 Mounting | 机柜式 (Rack-Mount) |
| 安规认证 Safety Certification | CCC |
| 标配 Standard | 型号 Model | 描述 Description |
| 35074KN00-704-G | AC Power Cable,1500mm,+70/-0mm,I-SHENG,T | |
| 35091QW00-0R3-G | SATA Signal Cable Assembly,400mm,+/-20mm |
| 选配 Optional | 型号 Model | 描述 Description |
| 35107V900-JTU-G | LPT Cable Assembly,450mm,+/-15mm,HO,HL12 | |
| 351061S00-JTU-G | GPIO cable with bracket, 350mm | |
| 35106BR00-38L-G | 1 to 2 USB Cable with bracket, 300mm+/-15mm | |
| 351091T00-0R3-G | Com*1 Bracket Cable,400mm,+/-10mm | |
| 351091S00-0R3-G | Com*2 Bracket Cable,400mm,+/-10mm | |
| 35107VA00-38L-G | PS2 KBMS /1*6Pin,400mm,+/-10mm,VSO,SR4H05621 | |
| 86011CJ00-01T-G | SPS,300W PFC,HUNTKEY,HK400-92FP S1 | |
| 86011CL00-01T-G | 350w FLEX PC Power,HUNTKEY,HK450-91PP | |
| 86020HY00-66A-G | SPS,450W 1U,GREATWALL,FLX450-50HUA |
