Intel® 6/7代酷睿 i7/i5/i3/奔腾®/赛扬®处理器, 功耗最高支援到95W, 支持intel vPro
双通道4插槽 DDR4 2133/2400MHz, 高达64GB
支持VGA, DVI-D, DP++ 3屏异显
支持双Intel GbEs, USB3.0, 16位GPIO
支持4个SATA3.0, RAID0/1/5/10
支持2个RS-232/422/485和2个RS232/485和2个RS232串联端口, 5V/12V电压输出
海岸线USB端口支援USB SR Pro技术
2个PCIe3.0 X16和3个PCIe X4 (X4 link), 2个PCI 扩展口, 和M.2 (SATA3.0或PCIe 3.0 x1 NVMe) 2242/2280
支持PS/2和前面板USB Port一键锁定功能
| 处理器 Processor | Intel® 6th/7th Gen Core ™ i7/i5/i3/Pentium®/Celeron® Processor, LGA1151 Socket, TDP up to 95W |
| 芯片组 Chipset | Intel® Q170 |
| 内存 Memory | Dual Channel, 4 x U-DIMM Slot, DDR4 2133/2400MHz, up to 64GB |
| 存储 Storage | 4 x SATA3.0, 1 x M.2 2242/2280 (SATA3.0/PCIe3.0 X1 supported) |
| 显示 Display | Intel® HD Graphics |
| 网口 Ethernet | 1 x Intel® i219-LM GbE, 1 x Intel® i210AT/211AT (10/100/1000 Mbps) |
| 音频 Audio | Realtek® ALC888S HD Audio codec, supports 2.1-channel |
| BIOS | AMI UEFI BIOS |
| 外部接口 Rear I/O | 1 x DVI-D: max resolution up to 1920 x 1200@60Hz 1 x VGA: max resolution up to 1920 x 1200@60Hz 1 x DP: max resolution up to 4096 x 2304@60Hz 2 x USB2.0, 6 x USB3.0 2 x RJ45 1 x RS232/422/485 (with auto flow control) 1 x Line-out, Line-in, Mic-in |
| 内部接口 Internal I/O | 1 x RS232/422/485 2 x RS232/485 2 x RS232 5 x USB2.0 (Type-A share USB signal with one USB2.0) 1 x 16 bit GPIO 4 x SATA3.0 1 x PS/2 (for Keyboard and Mouse) 1 x LPT |
| 扩展接口 Expansion | 2 x PCIe3.0 X16 (1 x 16 or 2 x 8 link) 3 x PCIe X4 (X4 link) 2 x PCI 1 x M.2 2242/2280 (SATA3.0/PCIe3.0 supported) |
| 信赖平台模块 TPM | Nuvoton TPM1.2 (optional, need MOQ) |
| 环境 Environment | 操作温度 Operation Temp.: 0℃ ~ 60℃ 存储温度 Storage Temp.: -40℃ ~ 85℃ 操作湿度 Operation Humidity: 5% ~ 95%, 非凝结状态 Non-condensing 存储湿度 Storage Humidity: 5% ~ 95%, 非凝结状态 Non-condensing |
| 电源输入 Power Input | ATX |
| 尺寸 Dimensions | 304.8 x 244 mm (12" x 9.6") |
| 操作系统 OS | 6th Gen CPU : Windows7/8/10, Linux 7th Gen CPU : Windows10, Linux |
| 看门狗 Watchdog Timer | System Reset, Programmable via software from 1 to 255 seconds |
| 标配 Standard | 型号 Model | 描述 Description |
| 35091AW00-JTU-G | SATA Signal Cable Assembly,400mm+/-20mm | |
| 2T7198600-G9F-G | IO挡板,IO shielding |
| 选配 Optional | 型号 Model | 描述 Description |
| 35107V900-JTU-G | LPT cable with bracket, 450mm, | |
| 351061S00-JTU-G | GPIO cable with bracket,350mm | |
| 35106BR00-38L-G | 1 to 2 USB Cable with bracket,300mm+/-15mm | |
| 351091T00-0R3-G | Com*1 Bracket Cable,400mm,+/-10mm | |
| 351091S00-0R3-G | Com*2 Bracket Cable,400mm,+/-10mm | |
| 480301K00-JV0-G | CPU Cooler, support 65W, LGA115X Series |
